stainless steel screening sieving Mesh
stainless steel screening sieving woven mesh
stainless steel food processing drying
stainless steel screening sieving Mesh
stainless steel screening sieving woven mesh
stainless steel food processing drying

In stock

Parent Code: SSWO

Screening Sieving Mesh

Stainless steel woven wire mesh for screening / sieving is engineered for precision and durability in various industrial applications. Stainless steel woven mesh offers excellent resistance to corrosion and wear, ensuring long lasting performance.

Common Applications

  • Aggregate and mineral screening
  • Grain and seed sorting
  • Pharmaceutical powder sieving
  • Food and beverage filtration

SSWM Stocked Screening / Sieving Mesh Range

We stock over 350 stainless steel woven mesh specifications in grade 304 and 316. Available in 30m, 10m, 5m & 2m rolls in varying widths.

REQUEST A QUOTE
Call Us 1300 304 316
Quality Assured & Tested Icon

Quality Assured & Tested

Same Day Despatch Icon

Same Day Despatch

Extensive stockist icon

Australia's Largest Stockist

Aperture

0.026mm to 35mm

Wire Diameter

0.025mm to 4.00mm

Grade

304 & 316

Length x Width

2m Rolls / Sheets x 1245mm width

10m length x 1550mm width rolls

30m length x 1245mm, 1550mm and 1830mm width rolls

Condition

Mill also known as off the machine

Still have questions?

Email Us Directly

Stainless Steel SCREENING / SIEVING MESH

Parent CodeMeshSWGAperture mmWire Diameter mmApprox % OpenMicronTechnical Data SheetRequest a Quote
Cutting Please place your woven wire orders that require cutting by 11:00am for same day cut and pick up by 2:30pm
TECHNICAL DATA SHEET
PRODUCT SELECTION GUIDE

Mesh is Tested / Manufactured to:

ASTM International (formerly American Society for Testing and Materials)
✔ ASTM E2016-15 ‘Standard Specification for Industrial Woven Wire Cloth’
Manufactured to
Technical Data Sheets
✔ Refer to SSWM Technical Data Sheets for further Standards / Testing information and which of the above are relevant to the mesh that you have selected
  • Refer to Technical Data Sheets for Specific Testing. We also provide a Material Test Certificate (MTC) for all of our products, a quality assurance document stating chemical composition to give you the confidence that you are receiving a quality product.

Stainless Steel
Woven Mesh Calculations

  • Mesh Count
  • Wire Diam mm
  • Aperture mm
  • Open Area %
  • Weight Squ m
  • Micron (if Aperture =< 1)
Sieving has traditionally been associated with the food industry. It was used to grade grain harvests centuries ago. Grains are sorted into different sizes to improve the processing of the grain. Grains once harvested can either be:
  • Unprocessed and sold as whole grains
  • Milled to produce grain flour
Grading of grains provides a consistent product that buyers can then use for their own processes. This improves the quality and productivity of the material being sieved.
Sieving can be used for any materials where sorting into different size fractions is required. It is important that the sieve material doesn’t contaminate the material being sieved. Therefore, the sieving material needs to be harder than the material being sieved. Selecting the right size opening is crucial to avoid problems with processing. Effective sieving depends on conditions such as humidity, product wetness, angle of repose, product size distribution, throughput, aperture size and open area. To overcome these challenges, the process may include air dryers, mechanical vibration and heating conveyors.
Sorting materials into size fractions helps improve the quality of the finished product. Grading allows the product to be sold at a higher price. Users specify the grade to reduce variation and improve overall quality or throughput. Size fractions affect surface area, which in turn influences:
  • The release of flavour
  • The cooking rate
Sieving is broadly considered to be the separation of materials in agriculture and food industries where size distribution is important. Equipment is designed with specific size fractions in mind. Sieving aperture sizes range between filtration and screening, typically from 0.1 mm (flour) to 10.0 mm (nuts).
Sieving can be completed with any material that has holes, including woven wire, welded wire and perforated sheets:
  • Woven wire: square and rectangular holes, small wire diameter, behaves like fabric, easy to cut and shape
  • Welded wire: Square and rectangular holes, larger wire diameter, behaves like a fixed screen
  • Perforated sheet: Holes can be round, square, or rectangular, produced with or without a border
Yes, open area impacts product throughput and operational efficiency:
  • Large open area may result in product passing through too quickly, causing buildup before the next process
  • Small open area restricts flow, potentially creating a backlog and blockage on the sieve
Yes, different materials have different size distributions. Sieving separates materials into two fractions: those that pass through (bottoms) and those that don’t (tops). Products may be processed and sieved multiple times. Apertures may change depending on raw material size variations. Users may purchase ungraded material and grade it themselves. Oversized material may be reprocessed, while undersized material may be downgraded and sold as seconds. Raw materials are often sorted into several sizes and directed to different production lines, including secondary sieving after crushing or grinding.
Bolting Cloth is used in the flour industry and has a higher open area for high-capacity sifting. Hollander Mesh uses two wire diameters for strength (larger wire) and open area (smaller wire), allowing good throughput. SSWM supplies these materials for specific applications.
SSWM has supplied woven, welded, and perforated sheets to various industries: Agriculture:
  • Sorting wheat using woven mesh
  • Sorting nuts using welded mesh
Food:
  • Sifting flour using bolting cloth
  • Pistachio nuts for Dubai chocolate using perforated sheet
  • Straining pasta from water using perforated sheet
Beverage Industry:
  • Coffee beans using woven mesh
  • Removing particulates from wine using Hollander mesh
SSWM can assist in identifying your sieve. If you provide a photo of the sieve with a ruler for scale, we may be able to identify it. Our database of mesh types and uses can help get your sieving operation back on track.
We have a datasheet for each product item, these include a to-scale image, specifications, dimensions and weights. These are found on the website in the far right column of the product tables. We also include a link to the relevant datasheet in all quotes, proformas and invoices.
WELDED MESH
5 lineal metres and increments of 5 lineal metres
WOVEN MESH
1245mm wide – 2 lineal metres and increments of 1 lineal metre 1550mm wide – 10 lineal metres and increments of 10 lineal metres 1830mm wide – 10 lineal metres and increments of 10 lineal metres
If we receive your order before 9am, it will be dispatched on same day.
Absolutely, we welcome you to use your own freight company.
We accept payment via PayPal or direct deposit EFT. We have a strict policy of not taking credit card details over the phone
No. We only cut across the width of the roll once. To enable speed to market, we have all specifications in pre-cut 2 m rolls in 1245mm wide and 10m rolls in widths above 1550mm, which are ready to be dispatched upon order.
Please place your woven wire orders that require cutting by 11am for same day cut and pickup by 2.30pm
Please do, to enable us to assist you with your enquiry and requirements without distractions.
Our opening hours are 8.30am – 3.30pm Monday to Friday
Our stocked size for stainless steel welded panels is 1200 x 2400mm However, for large volumes, panels can be custom-made
On a double skid for interstate and country deliveries, no double skid is usually required for local deliveries or local pickups.
Yes, please either send or bring your mesh in for identification. If emailing a photo, please ensure it is against a ruler, so we can identify the mesh count and wire diameter.
Yes, as our name suggests, we sell only Stainless Steel Wire & Mesh.
